Connectors for Masonry, Timber and Steel Construction

PBH

Heavy Duty Elevated Post Base

The PBH is suitable for heavy duty post support applications including Glulam timber posts,with a standoff height of 216mm. Dowels included.

PBH75 suitable for posts 75 x 75mm to 120 x 120mm
PBH120 suitable for posts 120 x 120mm to 200 x 200mm

Technical Data Sheet

CE Marking

ETA

Service class 3

Outdoor

Galvanised steel

Technical Data

Dimensions

Product Dimensions

References	Timber Post Size [mm]	Product Dimensions [mm]										Top plate holes	Bottom plate holes
References	Timber Post Size [mm]	A	B	C	D	E	F	G	H	t₁	t₂	Ø8,5	Ø14
PBH75	75x75 - 120x120	75	75	110	160	100	216	42.4	45	8	8	2	2
PBH120	120x120 - 200x200	120	120	110	155	155	216	42.4	90	8	8	4	4

Product characteristic capacities - Simplified values

References	Simplified product capacities - Timber to Concrete
	Number of Fasteners				Simplified characteristic capacities - Timber C24 [kN]
	On post		On concrete		R_1.k^*	R_2.k			R_3.k=R_4.k			R_5.k=R_6.k
	Qty	Type	Qty	Type		Width of the post [mm]			Width of the post [mm]			Width of the post [mm]
	Qty	Type	Qty	Type		80	100	120	80	100	120	80	100	120
PBH75	4	STD Ø8	2	Ø12**	105.5	8.1	9.5	10.4	5.5	6.5	7.1	5.8	6.6	7.3
PBH120	4	STD Ø8	4	Ø12**	156.4	20.7	20.7	20.7	7.7	7.7	7.7	7.3	7.9	8.5

*The published characteristic capacity is based on medium term load duration and service class 3 according to EC5 (EN 1995) ( k_mod = 0.7). For other load duration and service class, please refer to the ETA to get more accurate capacities.

**Refer to the Simpson Strong-Tie anchor product range for suitable anchors. Typical anchor solutions depend on the concrete type, spacing and edge distances.

Installation

Installation

Installation

Use the flitch plate to mark and drill the 8mm diameter holes for the dowels
Cut a 9mm slot in the side adjacent to the drilled holes, for the flitch plate
Fix to the foundation with M12 anchors
Lower the post onto the flitch plate, align the holes and fit the dowels
Not recommended when the top of post/column is not restrained (e.g. fence post)
Stainless steel option available to order

Certification

Declaration of Performance (DoP)

uk-dop-e07-0285-07.pdf (119.89 KB)

2020-05-18

uk-dop-e07-0285-06.pdf (118.42 KB)

2019-05-23

uk-dop-e07-0285-issue-5.pdf (117.65 KB)

2018-07-03

uk-dop-e07-0285-issue-4.pdf (117.96 KB)

2015-08-04

uk-dop-e07-0285-issue-2.pdf (76.42 KB)

2013-03-01

e3442fc0a0d50c71e44f42f67cf1b19c2bf63a58.pdf (75.79 KB)

European Technical Assessment (ETA)

eta-07-0285-2021-12-09.pdf (8.11 MB)

2018-06-12

eta070285-sst-pb-hd-r6-2018.pdf (8.84 MB)

ZIP Packages

2D
2D DWG ZIP 2D REVIT ZIP DXF ZIP PDF ZIP

3D/3D Simplified
3D REVIT ZIP IFC ZIP SAT ZIP SKP ZIP STL ZIP
